NE140WUM-N62 BOE 14.0" 1920(RGB)×1200 400 cd/m² INDUSTRIAL LCD DISPLAY

Ask Lasest Price
Brand Name :	BOE
Model Number :	NE140WUM-N62
Certification :	ISO9001
Payment Terms :	TT/PAYPAL/ESCROW/WESTERN UNION
Delivery Time :	1-2DAYS

Add to Cart

Product Details
Company Profile

NE140WUM-N62 BOE 14.0" 1920(RGB)×1200 400 cd/m² INDUSTRIAL LCD DISPLAY

BOE NE140WUM-N62 Application Details

Basic Information :	Brand		Model	NE140WUM-N62 1 Compatible
	Type	LCM Oxide TFT-LCD	Used For
	Screen Size	14.0"	Alias	BOE094C
Environment :	Storage Temp.	-20 ~~ 60 °C	Operating Temp.	0 ~~ 50 °C
Environment :	RoHS		Vibration	1.5G (14.7 m/s²)

BOE NE140WUM-N62 Mechanical Details

Pixel Features :	Resolution	1920(RGB)×1200	Dot Pitch(mm)	0.05236×0.15708 (H×V)
Pixel Features :	Pixel Format	RGB Vertical Stripe	Pixel Pitch(mm)	0.15708×0.15708 (H×V) [161PPI]
Mechanical Size :	Active Area(mm)	301.594(H) × 188.496(V)	Bezel Area(mm)	-
Mechanical Size :	Outline Dim.(mm)	306.594(H) × 197.6(V)	Depth(mm)	2.4/4.5 (Typ./Max.)
Outline Features :	Form Style	Flat Rectangle	Outline Shape	Slim (PCBA Bent, T≤3.0mm)
Outline Features :	Aspect Ratio	16:10 (H:V)	Orientation	Landscape type
Mounting :	Without
Other Spec :	Weight	200g (Max)	Treatment	Antiglare, Hard coating (3H)

BOE NE140WUM-N62 Optical Details

Basic Information :	Luminance(cd/m²)	400 (Typ.)	Contrast Ratio	1500:1 (Typ.) (Transmissive)
	Viewing Angle	89/89/89/89 (Typ.)(CR≥10)	Display Mode	HADS, Normally Black, Transmissive
	Best View on	Symmetry	Response(ms)	25 (Typ.)(Tr+Td)
Color Performance :	White Coordinate	X:0.313; Y:0.329	Display Colors	16.7M (8-bit)
Color Performance :	Color Temperature	6485K	White Uniformity	1.25/1.67 (Max.)(5/13 points)
1931 Color Gamut :	NTSC Ratio	74%	sRGB	99% coverage
	Adobe RGB	76% coverage	DCI-P3	77% coverage
	Rec.2020	55% coverage	Remarks	sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)

BOE NE140WUM-N62 Interface Details

Signal Electrical :	Voltage Supply	3.3V (Typ.)		Current Supply	121mA
Signal Electrical :	Consumption	0.34/0.4W (Typ./Max.)
Signal Type :	eDP (2 Lanes), eDP1.4, HBR1 (2.7G/lane)			Signal Voltage	-
Interface Features :	Position			Type	Connector
Interface Detail :	Brand	Model	Quantity	Pins	Pitch	Pin Configuration
Interface Detail :	I-PEX	20455-030E-0	1 pcs	30 pins	0.5 mm	EDP-30P2L-020A

BOE NE140WUM-N62 Backlight Details

Backlight Features:	Shape	7 strings	Type	WLED	Position	Edge light type
Backlight Features:	Replacement	-	Quantity	11S7P	Life Time	15K(Min.) (Hours)
Interface Features :	Position	-		Type	Included in signal interface
Backlight Driver :	With LED Driver
Driver Electrical :	Voltage Supply	5.0/12.0/21.0V (Min./Typ./Max.)		Current Supply	160mA (Max.)
Driver Electrical :	Consumption	1.88/1.92W (Typ./Max.)

whose pixels are arranged in RGB Vertical Stripe. As for mechanical detail, it features active area of 301.594(W)×188.496(H) mm, outline size of 306.594(W)×197.6(H)×4.5(D) mm, with surface treament of Antiglare, Hard coating (3H), net weight of 200g (Max), shape stype of Slim (PCBA Bent, T≤3.0mm). As a HADS, Normally Black, Transmissive LCM product, NE140WUM-N62 can provides 400 cd/m² display brightness 1500:1 transimissive contrast ratio, 89/89/89/89 (Typ.)(CR≥10) (L/R/U/D) viewing angle, best view direction on Symmetry , and response time of 25 (Typ.)(Tr+Td) ms. Gray scale or the brightness of the sub-pixel is determined with a 8-bit gray scale signal for each dot, thus presenting a palette of 16.7M colors, also with performance of color gamut 99% (sRGB). This product adopted 11S7P WLED as it's backlight systerm which was placed as Edge light type and have a working life time of 15K hours, With LED Driver. NE140WUM-N62 utilizes eDP (2 Lanes) as it's signal inputting systerm, which connected by 30 pins Connector with power supply voltage of 3.3V (Typ.).
